The Grundfos CMB5-37PT is a powerful automatic pressure booster pump designed for domestic and construction applications. This 670W single-phase electric pump delivers impressive performance with a maximum flow rate of 86 L/min and a maximum head of 37m. Featuring a durable cast iron body and stainless steel impeller, it operates quietly at under 70 dB. The pump offers reliable pressure control with built-in overload and temperature protection, making it ideal for home water systems.
Specifications
Price
Shopee
RM2,681.00
20 products
RM3,501.00
1 product
Specifications
Basic information
Brand
Grundfos
Model
CMB5-37PT
Product name
Pam Air Automatik (Tangki Tekanan)
Pump type
Pam Penambah Tekanan Air
Engine type
Elektrik
Motor type
1 Fasa
Safety features
Overload protection
Yes
Pressure switch control
Yes
Temperature protection
Yes
Warranty support
Certifications
WEEE
Warranty period
10 tahun (motor), 2 tahun (produk)
Warranty type
Pembatasan
Power specifications
Frequency
50
Frequency unit
Hz
Horsepower
0.898
Motor power
670W
Output power
0.898
Output power unit
HP
Voltage
220
Operating conditions
Ambient temperature limit
55
Ambient temperature unit
°C
Maximum water temperature
55
Temperature unit
°C
Features
Noise level
Kurang daripada 70 dB
Oil free
Yes
Performance
Maximum flow rate
86
Maximum flow rate unit
liter/min
Maximum head
37
Maximum head unit
m
Rated flow
20.7
Rated flow unit
US gpm
Suction depth
6
Suction depth unit
m
Suction head
6
Suction head unit
m
Construction
Impeller material
Stainless steel (EN 1.4301 / AISI 304)
Inlet outlet diameter
1 1/4 inci (suction), 1 inci (discharge)
Material
Cast iron (EN 1561 EN-GJL-200 / ASTM A48-30B)
Dimensions
Height
59.5
Height unit
cm
Length
28.4
Length unit
cm
Weight
23.3
Weight unit
kg
Width
36
Width unit
cm
Applications
Pembinaan, Domestik, Pam Air Rumah
