The FiiO Q5 is a versatile portable DAC/Amplifier crafted from aluminum with titanium finish. It supports high-resolution audio including DSD256 and PCM up to 384kHz/32-bit. Features Bluetooth 4.2 with aptX/AAC, balanced (2.5mm) and single-ended (3.5mm) outputs delivering up to 470mW and 230mW at 16Ω respectively. Boasts impressive 115dB SNR and 0.001% THD. 3800mAh battery provides 10 hours playback. Compatible with smartphones, tablets, and laptops.
Specifications
Price
Shopee
RM417.58
5 products(4 items sold out)
Specifications
Basic information
Brand
FiiO
Model
Q5
Amplification type
Portable
Product type
DAC/Amplifier
Colour
Titanium
Material
Aluminium
Warranty support
Standard warranty
1 Tahun
Support type
Rasmi FiiO Malaysia
Input specifications
Analogue inputs
Mini jack
1
Digital inputs
Coaxial
Yes
USB
Connector type
Micro USB
Supported
Yes
Optical
Yes
Power specifications
Battery
Charging time unit
hours
Charging time
3.5
Operating time
10
Capacity unit
mAh
Operating time unit
hours
Capacity
3800
Power supply
Current
2
Current unit
A
Type
DC
Voltage unit
V
Voltage
5
Features
Special functions
Bass Boost, Bluetooth 4.2 (aptX, AAC, SBC)
Volume control
Potentiometer (ADC Sampling)
Audio performance
Frequency response
Range
5Hz–50kHz
Tolerance
-3dB
Signal to noise ratio
Unit
dB
Value
115
Total harmonic distortion
Unit
%
Value
0.001
Physical specifications
Dimensions
Depth unit
mm
Depth
16
Height unit
mm
Width
124
Width unit
mm
Height
64
Weight
Unit
g
Value
195
Audio format support
DSD
Formats
DSD64, DSD128, DSD256
PCM
Sampling rates
384kHz, 192kHz, 96kHz
Bit depth
32bit, 24bit
Output specifications
Headphone outputs
Single ended
Power output
230mW (16Ω), 160mW (32Ω), 24mW (300Ω)
Connector type
3.5mm
Impedance
150
Impedance unit
ohms
Balanced
Power output
470mW (16Ω), 440mW (32Ω), 93mW (300Ω)
Connector type
2.5mm TRRS
Impedance
300
Impedance unit
ohms
Line outputs
Type
3.5mm
Compatibility
Recommended headphone impedance
Unit
ohms
Minimum
16
Maximum
300
Supported devices
Smartphones, Tablets, Laptops
