The FiiO E10 is a compact DAC/Amp from 2011 featuring the WM8740 DAC chip supporting 16/24-bit audio at 32-96kHz sampling rates. This black unit delivers clean audio with <0.003% THD, ≥100dB SNR, and 20Hz-20kHz frequency response. Notable features include a bass boost switch, USB input, 3.5mm headphone output, and RCA out. Operating at 5V with 16-ohm impedance, it measures 10.5x5.5x2.5cm and weighs 120g.
Specifications
Price
Shopee
RM180.00
9 products(All items sold out)
Specifications
Basic info
Brand
FiiO
Model
E10
Colour
Hitam
Manufacture year
2011
Type
DAC/Amp
Power specifications
Power output
THD
0.003
Channels
2
Impedance
16
Power supply
Power consumption
Standby
0.5
Operating
2
Voltage
5V
Frequency
50Hz-60Hz
Digital processing
DAC
Sampling rate
32kHz-96kHz
Model
WM8740
Bit depth
16/24
Additional features
Display type
LED
Special features
Bass boost switch
Included accessories
Kabel USB, Manual pengguna
Audio performance
Channel separation
≥70dB
Frequency response
20Hz-20kHz
Input sensitivity
Line
200mV
Signal to noise ratio
Line
≥100dB
Total harmonic distortion
<0.003%
Connectivity
Inputs
Digital
USB
1
Outputs
Analogue
RCA
1
Headphone
3.5mm
Warranty
Coverage
Terhad
Duration
1 tahun
Physical specifications
Dimensions
Unit
cm
Depth
5.5
Width
10.5
Height
2.5
Weight
Unit
g
Value
120
