The Lexar NM610 is a high-performance M.2 2280 NVMe SSD featuring PCIe 3.0 x4 interface and Silicon Motion SM2263XT controller with TLC NAND flash. It delivers impressive speeds of up to 2100MB/s read and 1600MB/s write, with random performance reaching 188K/156K IOPS read/write. Supporting TRIM and SMART monitoring, it includes Host Memory Buffer technology. The drive operates efficiently with 3.3W active power consumption and offers capacities from 250GB to 1TB.
Specifications
Price
Shopee
RM118.80
46 products(19 items sold out)
PG Mall
RM189.00
2 products
Specifications
Basic info
Brand
Lexar
Model
NM610
Product name
Lexar NM610 M.2 2280 NVMe SSD
Protocol
NVMe 1.3
Controller
Silicon Motion SM2263XT
Nand flash type
TLC
Release date
2020-01-01
Interface
PCIe 3.0 x4
Form factor
M.2 2280
Features
Additional features
Host Memory Buffer (HMB)
Smart monitoring
Yes
Trim support
Yes
Performance
Random read speed
188000
Random read speed unit
IOPS
Random write speed
156000
Random write speed unit
IOPS
Sequential read speed
2100
Sequential read speed unit
MB/s
Sequential write speed
1600
Sequential write speed unit
MB/s
Environmental
Operating temperature max
70
Operating temperature unit
°C
Reliability
Endurance rating
0.5 DWPD
Mtbf
1500000
Mtbf unit
hours
Terabytes written
500
Terabytes written unit
TBW
Warranty support
Warranty period
3 tahun
Warranty type
terhad
Power
Active power
3.3
Active power unit
W
Idle power
0.49
Idle power unit
W
Compatibility
Supported platforms
Desktop, Laptop
Dimensions
Height
2.25
Height unit
mm
Length
80
Length unit
mm
Width
22
Width unit
mm
Capacity
Available capacities
250GB, 500GB, 1TB
