The infiray T2S+ is a compact thermal imaging camera featuring a 256×192 infrared resolution and impressive thermal sensitivity of ≤60mK. With a wide 44.9°×33.4° field of view and 12μm spatial resolution, it offers precise temperature measurements from -20°C to 450°C. The device supports multiple measurement modes and connects via USB-C or Lightning ports. At just 18g and 26x26x24.2mm, it's highly portable and operates in temperatures from -20°C to 50°C.
Specifications
Price
Shopee
RM1,880.00
5 products(2 items sold out)
Specifications
Basic info
Brand
Infiray/Xinfrared
Model
T2S Plus
Series
T2S+
Type
Thermal Imaging Camera
Included items
Accessories
Type-C cable, T2S+ handle, Protective case, English manual
Environmental
Operating temperature max
50
Operating temperature min
-20
Temperature unit
°C
Warranty support
Warranty period
2 years
Warranty type
Standard + Extended
Measurement
Accuracy
±2°C or ±2%
Measurement modes
Point, Line, Area
Temperature range max
450
Temperature range min
-20
Temperature unit
°C
Imaging specifications
Field of view
44.9°×33.4°
Focus distance
8mm
Infrared resolution
256×192
Refresh rate
25
Refresh rate unit
Hz
Spatial resolution
12μm
Thermal sensitivity
≤60mK@25°C, F#1.0
Connectivity
Supported apps
Xtherm
Wired
USB-C, Lightning
Physical specifications
Depth
24.2
Depth unit
mm
Height
26
Height unit
mm
Weight
18
Weight unit
g
Width
26
Width unit
mm
Power
Charging method
USB-powered via smartphone
