The Grundfos CMB3-37PM1 is a powerful pressure booster pump delivering 0.5 kW output with a maximum flow rate of 70 L/m and head height of 40m. Built with cast iron body and stainless steel impeller, it's ideal for domestic water pressure boosting and light industrial applications. Features 1" inlet/outlet connections, low noise operation, and comprehensive safety protections. Compact at 324x270x301mm, it handles water temperatures up to 60°C.
Specifications
Price
Shopee
RM1,950.00
59 products(1 item sold out)
Lazada
RM1,990.00
7 products
Specifications
Basic information
Brand
Grundfos
Model
CMB3-37PM1
Product name
Grundfos CMB3-37PM1
Pump type
Pressure Booster Pump
Safety features
Overload protection
Yes
Pressure switch control
Yes
Temperature protection
Yes
Warranty support
Certifications
CE, CN ROHS EXE Model B, AS/NZS 4020
Warranty period
2 Tahun
Warranty type
Standard
Power specifications
Frequency
50
Frequency unit
Hz
Horsepower
0.67
Motor power
0.5 kW
Output power
0.5
Output power unit
kW
Voltage
220, 225, 230
Operating conditions
Ambient temperature limit
50
Ambient temperature unit
°C
Maximum water temperature
60
Temperature unit
°C
Features
Noise level
Rendah
Oil free
Yes
Portability
Padat
Performance
Maximum flow rate
70
Maximum flow rate unit
L/m
Maximum head
40
Maximum head unit
m
Rated flow
3.1
Rated flow unit
m³/h
Construction
Impeller material
Stainless Steel (EN 1.4301 / AISI 304)
Inlet outlet diameter
1” Female / 1” Male
Material
Cast Iron (EN 1561 EN-GJL-200 / ASTM A48-30B)
Dimensions
Height
301
Height unit
mm
Length
324
Length unit
mm
Weight
13.2
Weight unit
kg
Width
270
Width unit
mm
Applications
Domestic water pressure boosting, Rainwater tank systems, Light industrial pressure boosting
