The MSB MS 12-4.5 is a tower-style UPS offering 1200VA/675W capacity with simulated sine wave output. Features include Automatic Voltage Regulation, cold start function, and comprehensive protection against overload, short circuit, and surge. Operating on 230V with 160-280V input range, it includes 4 IEC C13 outlets and a 12V/7Ah user-replaceable battery with 6-hour recharge time. LED indicators and USB connectivity enhance monitoring capabilities.
Specifications
Price
Shopee
RM65.00
1 product
Specifications
Basic info
Brand
msb
Model
MS 12-4.5
Product name
MSB MS 12-4.5
Type
UPS
Form factor
Tower
Manufacturer
MSB
Environmental
Operating humidity
20-90% RH
Operating temperature
0-40°C
Warranty support
Certifications
CE, RoHS
Warranty period
2 tahun
Warranty type
Terhad
Input specifications
Frequency
50/60Hz
Frequency range
45-65Hz
Phase
Single
Voltage
230V
Voltage range
160-280V
Power specifications
Capacity va
1200
Capacity watt
675
Output waveform
Simulated Sine Wave
Power factor
0.56
Transfer time
4ms
Additional features
Avr
Yes
Special features
Automatic Voltage Regulation, Cold Start Function
Display interface
Display type
LED
Led indicators
Yes
Connectivity
Usb port
Yes
Output specifications
Frequency
50/60Hz
Frequency range
45-65Hz
Number of outlets
4
Outlet type
IEC C13
Voltage
230V
Voltage range
220-240V
Battery specifications
Capacity
7Ah
Recharge time
6 hours
Replacement type
User-replaceable
Type
Sealed Lead Acid
Voltage
12V
Protection features
Overload protection
Yes
Short circuit protection
Yes
Spike protection
Yes
Surge protection
Yes
Temperature protection
Yes
Voltage protection
Yes
