The Lincoln Ranger 305D is a versatile diesel-powered portable welding machine equipped with Chopper Technology®. Powered by a Kubota® D722 3-cylinder water-cooled engine, it delivers 20-305A output current with 7200W rated power. Supporting multiple welding methods including Stick, TIG, MIG, Flux-cored, and Arc Gouging, it offers 100% duty cycle at 250A. Features digital display and overheat protection in an IP23-rated housing.
Specifications
Price
Shopee
RM300.55
2 products
Specifications
Basic information
Brand
Lincoln Electric
Model
Ranger 305D
Working form
Stick, TIG, MIG, Flux-cored, Arc Gouging
Drive form
Kubota® D722, 3-silinder, berpendingin air
Type
Mesin las diesel portabel
Features
Digital display
Yes
Overheat protection
Yes
Electrical specifications
Rated power
7200
Rated power unit
W
Technology
Chopper Technology®
Output specifications
Duty cycle
Current
250
Current unit
A
Percentage
100
Output current
Min
20
Max
305
Protection ratings
Housing protection level
IP23
Insulation class
H
Welding capabilities
Current type
DC
Welding method
Stick, TIG, MIG, Flux-cored, Arc Gouging
Certifications
CSA, ISO 9001
Dimensions
Dimensions unit
mm
Height
1327
Length
909
Weight
317
Weight unit
kg
Width
546
