The HIKMICRO B10 is a professional thermal imaging camera featuring a 256 × 192 infrared resolution and impressive thermal sensitivity of <40 mK. With a temperature detection range of -20°C to 550°C (±2°C accuracy), it offers versatile measurement modes including Center Spot and Hot Spot tracking. The device sports a 3.2-inch LCD display and 16GB internal storage. Built for durability with IP54 protection and 2m drop resistance, it operates up to 6 hours on Li-ion battery.
Specifications
Price
Shopee
RM2,091.24
2 products
Specifications
Basic info
Brand
HIKMICRO
Model
B10
Series
B Series
Type
Kamera Termografi Inframerah
Included items
Accessories
Panduan Pantas, Adaptor (×5), Kabel USB, Adaptor kuasa, Tali pergelangan tangan
Environmental
Operating temperature max
50
Operating temperature min
-10
Temperature unit
°C
Display
Resolution
240 × 320
Size
3.2
Size unit
inci
Type
LCD
Storage
Internal memory
16 GB EMMC
Storage capacity
~90,000 imej
Storage media
EMMC
Supported formats
BMP
Measurement
Accuracy
±2°C atau ±2%
Measurement modes
Center Spot, Hot Spot, Cold Spot, User Preset Point
Resolution
<40 mK
Temperature range max
550
Temperature range min
-20
Temperature unit
°C
Imaging specifications
Field of view
37.2° × 50.0°
Focus distance
0.3 m
Infrared resolution
256 × 192
Refresh rate
25
Refresh rate unit
Hz
Spatial resolution
3.3 mrad
Spectral range
8–14 μm
Thermal sensitivity
<40 mK
Connectivity
Wired
USB Type-C
Physical specifications
Depth
80.5
Depth unit
mm
Drop resistance
2 m
Height
221.7
Height unit
mm
Protection class
IP54
Weight
360
Weight unit
g
Width
73.5
Width unit
mm
Power
Battery life
6 jam
Battery type
Li-ion
Charging method
USB Type-C
Voltage
3.7
Voltage unit
V
