The H3C Magic NX30 is a high-performance Wi-Fi router featuring Wi-Fi 6 (802.11ax) technology with dual-band support (2.4GHz/5GHz). Powered by a Qualcomm IPQ5000 dual-core processor at 1GHz, it delivers combined speeds up to 2976Mbps. The router boasts advanced features like MU-MIMO, OFDMA, and WPA3 encryption for enhanced security. With 4 omnidirectional antennas and 3 Gigabit LAN ports, it offers excellent coverage and connectivity options.
Specifications
Price
Shopee
RM429.06
1 product
Specifications
Basic information
Brand
H3C
Model
NX30
Product name
H3C Magic NX30
Product type
Pengehos Wi-Fi
Release date
2023-04-01
Antenna
Gain level
5
DBi
dBi
Quantity
4
Type
Omnidirectional
Management features
Guest network
Yes
Mobile app
Yes
QoS
Yes
Remote management
Yes
Traffic monitoring
Yes
Web interface
Yes
Power specifications
Input voltage
12V
Power consumption
12
Watts
W
Power supply type
DC
Certifications
CE, WEEE, RoHS, CQC, SRRC
Security features
Encryption protocols
WPA3
Firewall
Yes
MAC filtering
Yes
Parental controls
Yes
Package contents
Accessories
Power adapter, Cat 5e networking cable
Documentation
Quick start guide
Warranty
Duration
365 hari
Type
Pembaikan percuma
Hardware specifications
Memory
MB
MB
RAM
256
Processor
Cores
2
MHz
GHz
Model
Qualcomm IPQ5000
Clock speed
1
Physical specifications
Dimensions
Mm
mm
Depth
222
Width
210
Height
64
Wireless specifications
Frequency ranges
2.4 GHz
2.4GHz-2.483GHz
5 GHz
5.15-5.35GHz, 5.725GHz-5.850GHz
Maximum data rates
Total
2976
2.4 GHz
574
5 GHz
2402
MIMO technology
2x2
MU MIMO
Yes
OFDMA
Yes
WiFi bands
2.4GHz, 5GHz
Environmental specifications
Operating temperature
Unit
°C
Maximum
40
Network standards
Ethernet standards
10/100/1000Base-T
Networking protocols
IPv6
Wireless standards
802.11ax, 802.11ac, 802.11n, 802.11g, 802.11b, 802.11a
Ports and interfaces
DC in jack
Yes
Ethernet LAN ports
3
Ethernet speed
1Gbps
Ethernet WAN ports
1
