The Oscal Pilot 3 is a rugged smartphone featuring IP68/IP69K protection and a large 6.78" IPS LCD display with 120Hz refresh rate. Powered by MediaTek Dimensity 6300 and running Android 15, it packs 12GB RAM and 256GB storage. The device boasts a 50MP main camera with night vision capabilities and a 32MP selfie camera. With 5G connectivity, 7500mAh battery, and 33W charging, it's built for endurance. Notable features include dual SIM support, NFC, and side-mounted fingerprint sensor.
Specifications
Price
Shopee
RM1,559.00
1 product
Specifications
Basic information
Brand
Oscal
Model
Pilot 3
Product name
Oscal Pilot 3
Ingress protection
IP68/IP69K kedap debu dan kalis air (semburan air tekanan tinggi; boleh tenggelam hingga 1.5m selama 30 min)
Color
Black、Orange
Release date
2025-06-01
SIM
Nano-SIM + Nano-SIM
Dimensions
Depth
14.5
Depth unit
mm
Height
182.2
Height unit
mm
Weight
357
Weight unit
g
Width
86
Width unit
mm
Platform
Chipset
Mediatek Dimensity 6300 (6 nm)
CPU
Octa-core (2x2.4 GHz Cortex-A76 & 6x2.0 GHz Cortex-A55)
GPU
Mali-G57 MC2
OS
Android 15, DokeOS 4.1
Memory
Card slot
microSDXC (menggunakan slot SIM kongsi)
RAM
12
RAM unit
GB
ROM
256
ROM unit
GB
Camera
Main
Camera 3
Type
Lensa bantuan
Features
Lampu kilat LED、HDR、panorama
Camera 1
Mode
lebar
Aperture
f/1.8
Sensor size
1/2.76"
Type
kanta biasa
Auto focus
PDAF
Pixel
50 MP
Camera 2
Mode
penglihatan malam
Aperture
f/2.0
Sensor size
1/2.8"
Type
lampu penglihatan malam inframerah
Pixel
20 MP
Video
Formats
1440p@30fps、1080p@30fps
Selfie
Features
HDR
Camera 1
Mode
lebar
Aperture
f/2.2
Sensor size
1/3.1"
Type
kanta biasa
Pixel
32 MP
Video
Formats
1080p@30fps
Display
Panel
IPS LCD
Protection
Corning Gorilla Glass 5, tahap Mohs 5
Refresh rate
120
Resolution
1080 x 2460 piksel (~396 ppi ketumpatan)
Size
6.78
Battery
Capacity
7500
Capacity unit
mAh
Charging
33W berwayar、6W berwayar songsang
Communications
Bluetooth
5.2、A2DP、LE
NFC
Yes
Positioning
GPS、GALILEO、GLONASS、BDS、QZSS
Radio
Yes
USB
USB Type-C, OTG
WLAN
Wi-Fi 802.11 a/b/g/n/ac、dual-band
Sound
Loudspeaker
Ya
TRS
Yes
Penanda Aras
Skor AnTuTu SoC
528398
Versi AnTuTu SoC
v11
Skor Geekbench Berbilang Teras SoC
1980
Skor Geekbench Teras Tunggal SoC
771
Versi Geekbench SoC
v6
Nama SoC
MediaTek Dimensity 6300
Network
Bands
5G
1, 3, 5, 7, 8, 20, 28, 38, 40, 41, 77, 78, 79
4G
1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 18, 19, 20, 25, 26, 28, 30, 34, 38, 39, 40, 41, 66
3G
HSDPA 800 / 850 / 900 / 1700(AWS) / 1900 / 2100
2G
GSM 850 / 900 / 1800 / 1900 、CDMA 800 / 1900
Speed
HSPA、LTE、5G
Technology
GSM、CDMA、HSPA、LTE、5G
Features
Sensors
Fingerprint (side-mounted)、accelerometer、gyro、proximity
